DURMA PBH 100 PROFILE BENDING MACHINE

DURMA PBH 100 PROFILE BENDING MACHINE

orCall (604) 472-1444

Description

FEATURES:

  • Robust machine frame is manufactured with rugged steel construction and machined after welding for rigidity
  • Large shaft diameters and bearings result in precise bending and also minimize deflection
  • A strong frame and world class components provide a long machine life
  • High drive torque and speed produce short cycle times
  • Minimized straight edge by hydraulic adjustments
  • Low energy and maintenance costs because of friction free planetary swing guides
  • Powerful guide rolls
  • Tie Bar Assembly
  • Bottom Rolls Digital Readout (X, Y Axis)
  • All Rolls Driven by Planetary Gear Box and Hydra motor
  • 1 Set Standard Hardened and Ground Rolls made of special steel
  • 3 Axis Side Supports-front-back, up-down, left-right manual adjustment
  • Special support for angle iron
  • Hydraulic Side Supports Z axis
  • Movable Command Panel Separate from Machine-NC
  • Horizontal Working Feature
  • Stress-Relieved Steel Construction Body
  • Electrical and Hydraulic Protection Against Overload
  • Roll Diameters 315mm / 12”
  • Bending Speed 7.5 meters/minute
  • Motor Power 15 HP, 220/440 Volt, 3PH
  • Shaft Diameters 110-100 mm / 4.33” – 3.93”
  • Dimensions 69” L x 53” W x 65”H
  • Weight 7,392 lbs

    • INCLUDES:

  • HYDRAULIC SIDE SUPPORTS (Z, U, C axis)
  • NC CONTROL SYSTEM (X, Y, R, Z axis)
  • VARIABLE TURN SPEED
    • Show All

    Specifications

    ManufacturerDurma
    ConditionNew
