STANDARD FEATURES
Both upper roll and central pinch rolls driven by electric motor and oil bath speed reducer through NiCrMo solid stock gears
Base in steel, electro-welded and stress relieved
Lateral roll, idle and moving on roller bearings
Pinch roll pinch pressure adjustable by precision worm gear movement
Yoke type drop end for top toll release, manual, for part removal
Top roll lifting via hydraulic jack, manual, further facilitates part removal
Lateral roll movement via electric motor and heavy duty worm gear drive for precise positioning and maximum power
Lateral bending roll and pinch roll incline for cone working
Low voltage push button controls via mobile control console
Multi point safety system including circumferential trip wire
Forced lubrication system
Instruction manual
BENDING CAPACITIES (* at full roll width)
Minimum diameter obtainable with thinner sheets 1.4 times top toll diameter allowing for material spring back – data calculated using certified mild steel yield point of 36,000 psi
OPTIONAL EQUIPMENT
Induction hardened rolls, required for most applications
Polished roll surfaces for bright or polished materials
Cone rolling attachment
Hydraulic powered drop end & top roll suspension
2 LED readouts with position preset for lateral rolls (1 each roll)
1 LED readout on pinch roll
LED readout on roll rotation (material translation) with memory preset
